> Fluke networks 685 enterprise lanmeter CAT5 cable test
Fluke networks 685 enterprise lanmeter CAT5 cable test
Included Accessories Listed at the Bottom.
Be sure to add us to your Favorites list!.
Warranty: 30 Day Exchange Warranty
* Troubleshoots and manages 10/100 Ethernet and Token Ring networks
* Frame relay, ISDN and T1/E1 troubleshooting
* Direct connectivity to test 100BASE-TX networks
* A large range of enhancement options for full network vision
* Auto-negotiate sensing capabilities Product Capabilities
The isolated nature of a switched network can be a nightmare for Network Engineers who are responsible for troubleshooting problems in these environments.
The Enterprise LANMeter Series provides you with troubleshooting and management capabilities for 10/100 Ethernet and Token Ring networks. With the SwitchWizard» option you can browse switch, router and other SNMP statistics in a graphical user friendly manner. You can also dig into frame relay, ISDN and T1/E1 configurations to check utilization and connectivity problems.
The new WebRemote Control Option lets you access the power of the Enterprise LANMeter regardless of where you are. Web access capability, which allows you to view troubleshooting and analysis information using your web browser, comes standard on LANMeter instruments with version 8.52 or higher.
For 685 users, enhancement kits are available to allow you to convert your existing LANMeter product to a 686 Enterprise LANMeter capable of direct connection to Fast Ethernet networks.
Plummeting per-port costs for Fast Ethernet hubs and user demands for higher bandwidth to the desktop are forcing many networks to adopt 100BASE-TX as the technology of choice for growth and for replacement of aging hardware. To support this trend, Fluke added direct connectivity for 100BASE-TX to the already popular Enterprise LANMeter series test tools.
0 m (0 ft) measures right up to connection point
BNC (ThickLAN) 600 m (2000 ft)
(BNC Connector): 0 ohms to 200 ohms
±(1% of reading +0.3 m (1 ft))
30 to 300 meters (100 to 1000 ft) ±2% of reading
The LANMeter time stamps the beginning and end of tests from an internal real-time clock.
Files may be saved internal to the unit. These files include screen captures, ASCII formatted scrolling lists and data log information. The File manager provides management for saved files by allowing export to a PC via the LANMeter serial port or E-Mail over a network connection.
A list of 512 addresses can be stored which establishes a symbolic name for MAC, IP, VINES IP and IPX addresses. Multiple station lists will support a maximum of 4096 stations.
The LANMeter analyzer's Flash ROM technology protects your investment by allowing software updates to be loaded quickly and easily from you PC via an RS-232 serial link.
Fluke 685 Enterprise LanMeter
(3) Fluke Cable Identifiers
FLuke 685 Users Manual On CD
