No. 2 moore precision jig borer, very nice (17303)
No.2 Moore, 10-1/2" x 16 1/2" Travel, 10" x 19" Table, Very Nice, Low Price Our stock number: 17303
MODEL...................................No. 2
SERIAL NUMBER...........................5169
Table Working Surface...................10" x 19"
Table Travel Longitudinal...............16-1/2"
Table Travel Crosswise..................10-1/2"
Table Top to Spindle End................Min. 5", Max. 20"
Vertical Adj. of Quill Housing..........10"
Spindle Quill Travel....................5"
Spindle Center to Column Ways....,......10"
Spindle Center to Column Below Ways.....11 1/2"
Tool Steel......5", Soft Steel......7"
Spindle Sensitive Enough For Drilling Holes
With #80 Drill (.0135) or Smaller
Two-Speed Motor........................75-2400 R.P.M.
Spindle Feed: 3 Feeds - .0015", .003", .006"
Machine With Regular Equipment,
Including Motor........................3275 Lbs.
Floor Space.............................48" x 52" x 7' High
2/1 HP Two Speed Motor, 208/60/3
All items are sold SPECIFICATIONS SUBJECT TO VERIFICATIONS.
All items are offered locally and could be sold previous to end of store listing.
**********PLEASE READ BELOW**********
**Skidding, crating, palletizing and/or packaging of any item are an additional cost and will be added to the items final purchase price. Skidding fees range from a minimum of $50.00 +. **
**We will load on a flat bed, open truck or trailer free of charge. **
**Skids shown in pictures are not included with the item. **
If you want to purchase an item and have circumstances requiring the item to be picked up at a later date, please inform us before the item is purchased.
We thank you in advance for your interest in this item. Please feel free to call or e-mail us with any questions or other machinery requirements. (***)-745-6008
