42" VERTICAL MILL, Sharp LMV-42 Special Packa
42" VERTICAL MILL, Sharp LMV-42 Special Packa
Special Package Price Includes:
- DVS (Digital Variable Speed) Head
- Newall 2 Axis Digital Readout
- Installation of above options
Working Surface...................... 9 x 42"
T-Slot Number, Size.................. 3, 5/8"
Table Travel: X-Axis................. 30"
Saddle Travel: Y-Axi................. 12"
Ram Travel........................... 12"
Quill Travel: Z-Axi.................. 5"
Knee Travel.......................... 16"
Spindle to Column (min-max).......... 6-3/4 - 18-1/2"
Spindle to Nose to Table............. 2-1/8 - 18"
Motor................................ 3 hp
Wiring Voltage....................... 220V, 1Ph or 3Ph, 60Hz
Taper................................ R-8
Speed (vari speed)................... 60-4,500 RPM
Quill Feed (IPR)..................... 0.0015, 0.003, 0.006"
Head Swivel.......................... 360 degree
Head Tilt; right-to-left (each way).. 45 degree
Head Tilt; up-and-down (each way).... 45 degree
Floor Area (w x d)................... 7 x 6.5"
Net Weight (approximately)........... 2,400 lbs.
3 HP Digital Variable Speed head w/Digital RPM Readout
Highly Reliable Yaskawa Inverter Drive System w/fewer moving parts
ABEC-7 Super-Precision Spindle Bearings
Self-Lubricating Motor Shaft - extends pulley life
Front and rear rubber way covers
OPTIONAL ACCESSORIES (call for pricing):
Power feeds for table, saddle and/or knee with safety handles
Kurt or Imported Milling vises
Right-angle milling attachment
D.R.O. system (Acu-Rite, Newall & Sony can be factory installed)
Kurt or Imported Power drawbars
Transformer for operation on 440 volts
Machine Location: HARRISON, NJ
