Exfo ftb-300 sm otdr ftb-7323B vfl power meter ftb-3922
EXFO FTB-300 Universal Test System with FTB-7423B-B-EI Singlemode 1310nm 1550nm OTDR, FTB-3922-23BL-EI Singlemode MultiTest Module
This Unit Has Just Returned From CALIBRATION!
Offers cutting edge OTDR module to efficiently detect, locate, and
analyze fiber splices, connectors, breaks, and other events along a fiber link, as well as a fiber's loss budget. From high-resolution measurements to high dynamic range requirements, the FTB-300 UTS acts as the perfect mini-OTDR.
Included Accessories Listed at the Bottom.
Be sure to add us to your Favorites list!.
Warranty: 30 Day Exchange Warranty
The FTB-300 Universal Test System (UTS) provides a simple, yet efficient,way to perform multiple advanced test operations in outside plant
installation,maintenance, and troubleshooting. EXFO FTB-7323B-EI Singlemode OTDR ModuleSpecs: Wavelength: 1310 ± 20/1410 ± 10/1550 ± 20/1625 ± 10Dynamic Range: (dB) at 10: 40/37/40 l/38Dynamic Range (dB) at 20: 41.5/38.5/40.5 l/39Event dead zone (m): 3 / 3 / 3 / 3Event dead zone (m): 10 / 10 / 15 / 16
EXFO FTB-3922-23BL-EI Singlemode MultiTest Module
* 1625 nm testing provides worst-case attenuation for the L band
* Fiber identifier detects 2 kHz signals
* Notepad feature documents power meter results in the field or in the office
* Power meter or optical loss test set uses manual or automated operation
* Singlemode or multimode, digital talk set, offers full-duplex hands-free communication
* Visual fault locator features 650 nm visible bright red source
* Ultra-High-Power power meter models
* Wavelength range (nm): 780 to 1625
* Measurement range (dBm): 10 to –68
* Uncertainty (%) 3,4 ± 5 ± 5
* Linearity (dB): ± 0.06 (10 to –48 dBm)
* Wavelengths (nm): 1310 ± 25/ 1550 ± 25
* Spectral width (nm): ≤ 5/5
* Output power (dBm): ≥ -3.5/-5.5
* Stability (8 hours) (dB): ± 0.10
* Wavelengths (nm): 1310/1550
* Maximum deviation (dB): ± 0.35/± 0.5
* Output power (CW) (dBm): -1
Offers cutting edge OTDR module to efficiently detect, locate, and
analyze fiber splices, connectors, breaks, and other events along a fiber link, as well as a fiber's loss budget. From high-resolution measurements to high dynamic range requirements, the FTB-300 UTS acts as the perfect mini-OTDR. The unique FTB-300 UTS combines a series of high-performance test modules in a powerful platform. The test set simultaneously houses up to three field-interchangeable modules. Its PC architecture runs the Windows 95 operating system as well as a complete test application software to provide maximum processing capability right where you need it the most: in
the field. The power of a UTS lies in its capability to evolve with technology and your needs;
therefore, the FTB-300 UTS provides you with the widest selection of test modules available. From power readings and OTDR testing to optical switching and optical spectrum analysis, the FTB-300 UTS does it all. And the family of plug-and-play modules continues to grow with the continuous introduction of new test modules. Modularity Means Flexibility Customized to your needs The main advantage of the FTB-300 UTS is that the end user can customize it to suit the work environment. Field-interchangeable modules allow the operator to modify the test tool capabilities in a matter of seconds, and as many times as required in a days work. A sound long-term investment The open architecture of the FTB-300 UTS provides obvious cost advantages since a single test system is shared between many applications.Without changing the platform, the test set can also be modified with new modules or software upgrades to provide the latest technologies at a
fraction of the cost. The FTB-300 UTS really reduces the strain on the test tool budget. A rugged, portable field unit
The FTB-300 UTS is designed to resist the rigors of the worst field conditions as well as stand the test of time. The unit offers shock-proof casing to withstand drops and vibrations. The large, sturdy touchscreen is resistant to shock,water, dust, and common chemicals. The outershell is waterproof with sealed joints, and door panels protect connectors, ports, and the floppy disk drive. The FTB-300 UTS also complies to all
* FTB-300 Universal Test System (UTS)
* SM OTDR Module FTB-7423B-B-EI
* SM MultiTest Module FTB-3922-23BL-EI
* Option: (VFL) Visual Fault Locator
* 1- SC to ST SM Fiber Patch Cord
* 1- SC to FC SM Fiber Patch Cord
