> Tek DC503A dc-503A dc 503A service & operations manual
Tek DC503A dc-503A dc 503A service & operations manual
* Hyperlinked Table of Contents & Theory of Operation sections.
* FULL SIZED A3, 11X17 inch scans of schemtics and fold out pages.
* Electronic Page numbers = actual page numbers (1-1, 2-3 etc)
Text with photos: 600dpi, grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes: 256 colors 600dpi
Large fold out schematic pages are scanned in sections at 8.5 X 11 with a typical over lap of 1" to insure easy piecing if you print them out.
Samples: of the actual pages from this scan available on request, email us a ****@artekmedia.com
