TOOL & CUTTER GRINDER, Cincinnati-Milacron #2
TOOL & CUTTER GRINDER, Cincinnati-Milacron #2
No. 2 Cincinnati-Milacron Universal Tool & Cutter Grinder
Model: #2MT, S/N: 1D2F1AAF134, New: 1974
Swing over table:................ 10'1/2" diameter
left hand tailstocks:.......... 33"
Table working surface:........... 6" x 44"
Longitudinal movement of table:.. 24"
Cross movement of table:......... 10"
Table swivels:................... 180 degrees
Table graduations in center:..... 90 degrees
spindle:....................... 10-1/2"
Grinding wheelhead swivels:...... 360 degrees
Grinding wheelhead tilta above
and below center:.............. 15 degrees
spindle to table top:.......... 13 - 5/8"
6" wheel, surface speed 6,110 FPM: 3,834 RPM
3-1/2"wheel, surface speed 5985 FPM: 6,425 RPM
Anti friction ball bearing rolling in replaceable
Swivelling & tilting wheelhead
Duplicate controls operating the machine at the
front, right, or left hand end of the table, or
at the rear, right, or left hand side of the column
BIJUR one-shot lubricatin system
1 HP 3/60/575 volt grinding wheel drive motor
Cincinnati-Milacron Motorized Workhead,
3/4 HP 3/60/575 Volt, mounted on swivel base
with a manual draw bar for type 5C Collets
C-M Manual Workhead mounted on swivel base with a
#50 N.S.T. at one end and a #5 Morse Taper
C-M Small Workhead attachment with #40 N.S.T. spindle
nose, 24 division master index plate, collet
adapter, and 10 assorted collets ranging in size
Left and right hand tailstocks
"Tange Bar" taper setting device permitting quick
and precise positioning of the swivel table when
(1) Wheel guard & (1) diamond holder with diamond
** Very Good Condition & Appearance **
** F.O.B. Hauppauge, Long Island, NY **
Machine Location: Long Island, NY
