Allen 2-spindle drilling machine 2 spd 1978
http:// /images/islogo_lg.gif
Allen 2-Spindle Drilling Machine 2 SPD 1978
Allen 2-Spindle Drilling & Tapping Machine
Serial No. VB-33875 New 1972
Drilling Capacity: 1" Diameter
Throat Distance to Vertical Ways: 12"
Throat Distance to Vertical Column: 13-1/2"
Maximum Distance Spindle Nose to Table Top: 25-1/2"
Distance Between Spindles: 25"
Vertical Head Adjustment: 6"
Vertical Table Adjustment: 16"
Spindle Speeds, Variable: 240 - 2400 RPM
Maximum Recommended Table Load: 500 Lbs.
Overall Machine Dimensions: 53" x 55" x 7'6" High
Machine Weight, Approx.: 3,000 Lbs.
Hand Controlled Tapping Attach. on RH Head
(2) Jacobs 0 - 1/2" Cap. Drill Chucks
Operator's & Maintenance Manual
Quill Stop Collars & Gauge Screws
Production Style Work Table
(2) 2 HP Variable Speed Spindle Motors 230/460/3/60
All Items Subject to Prior Sale
Be Sure to Verify Specs & Condition Prior to Purchasing
