Tek tektronix 1240 / 1241 service manual volume 1
Tektronix 1240/1241 Service Manual, Vol 1
This factory service manual is in good condition, is intact, complete, and perfectly readable in all respects. There is a split area about two inches in length along the back edge of the binder that in no way affects the readability of the manual. It includes a short (~14 pgs.) operating section plus general information, theory of operation, specifications, verification and adjustment procedures, disassembly and installation procedures, maintenance procedures, and troubleshooting and repair information.
Along with this original service manual volume 1 we will also include the 11 volume CD of our high quality/content division (aa4df) as described in item number 7564574965 which includes volume 2, a PDF copy of volume 1, and the other seven volumes described in 7564574965 plus two more that are not mentioned in that listing (though they are also included in sales from that listing). Please note that though listed as a 9 volume set, 7564574965 is in reality 11 volumes. Volume 2 includes electrical and mechanical parts lists, schematics and pc-board illustrations including parts placement diagrams.
For the sake of clarity, we elucidate: Volume One of the Service Manual is sent in book form, as pictured. As a free addition, a PDF version of Vol 1 plus PDF versions (that is to say, electronic documents on CD) are sent of:
SERVICE MANUAL VOLUME 1 - 798 pages
SERVICE MANUAL VOLUME 2 - 253 pages
GPIB COMM PACK USER MANUAL - 102 pages
PERFORMANCE ANALYSIS ROM PACK MANUAL - 36 pages
SERVICE ADDENDUM - 1241 Service Manual Addendum, designed to be used with the 1240/1241 Logic Analyzer Service Manual and contains only information that pertains exclusively to 1241 instruments. - 244 pages
P6460 INSTRUCTION MANUAL - Instruction manual for 6460 Data Acquisition Probe - 16 pages
1240 MICROPROCESSOR ANALYSIS WORKBOOK - yes, the same one you've seen listed at $25-40 - 152 pages
1240 WORKBOOK (Hardware, Software Analysis and Integration Techniques) - 58 pages
The book sent is Tek #: 070-4342-01, Revision of September, 1985
Again, we repeat: Only Volume 1 of the service manual is sent as a book. This is a very large volume that weighs eight pounds and is 3-3/4" thick at the bound end. The other volumes are sent on a CD, which is included as a free bonus.
-Absolutely NO International Sales On This-
